ZXR-10A 200mA Transformer Winding Resistance Tester AC220V

Name: ZXR-10A 200mA Transformer Winding Resistance Tester AC220V
Brand: Wuhan GDZX Power Equipment Co., Ltd
SKU: ZXR-10A
Price: 1599 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: GDZX

Certification: ISO9001

Model Number: ZXR-10A

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 1599USD

Packaging Details: carton

Payment Terms: L/C,T/T,Western Union,MoneyGram

Supply Ability: 500pcs/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                Transformer Winding Resistance Tester AC220V, AC220V Transformer DC Resistance Tester, 200mA Transformer Winding Resistance Tester


Product Name:	Transformer DC Resistance Tester	Output Current:	<5mA ,40mA,200mA,1A,5A,10A
Accuracy:	0.2% ± 2μΩ	Resolution:	0.1μΩ
Operating Temperature:	-20~40℃	Environment Humidity:	≤80%RH,No Condensation
Warranty:	1 Year	Working Power:	AC220V
Volume:	400220320mm³	Weight:	10kg

Product Name:	Transformer DC Resistance Tester
Output Current:	<5mA ,40mA,200mA,1A,5A,10A
Accuracy:	0.2% ± 2μΩ
Resolution:	0.1μΩ
Operating Temperature:	-20~40℃
Environment Humidity:	≤80%RH,No Condensation
Warranty:	1 Year
Working Power:	AC220V
Volume:	400220320mm³
Weight:	10kg

Product Description

ZXR-10A Transformer Winding Resistance Tester

Product Introduction :

ZXR-10A Transformer Winding Resistance Tester adopts new power supply technology, featuring small size, light weight, large output current, wide range and digital display. The whole machine is controlled by single-chip microcomputer, which automatically completes functions such as self-test, data processing and display, and has automatic discharge and discharge indication functions. The instrument has high test accuracy and easy operation, and can realize rapid measurement of direct resistance. The instrument has a built-in lithium battery, which is very convenient for field test work.

Main characteristics:

The instrument has a large output current and is light in weight.
The instrument provides 7-speed output current selection, which can output up to 10A current.
The measuring range of the instrument is 0uΩ-20KΩ.
With perfect protection circuit, the performance is more reliable.
Lithium battery power supply for easy on-site operation.
The LCD prompt menu is easy to use.
It has sound and liquid crystal indicating discharge alarm, clear discharge index and reduce misoperation.

Technical indicators:

1. Output current:10A,5A,1A,200mA,400mA,40mA,<5mA

2. Range:0-180mΩ (10A)
180mΩ-360mΩ (5A)
360mΩ-1.8Ω (1A)
1.8Ω-4.5Ω (400mA)
4.5Ω-9Ω (200mA)
9Ω-45Ω (40mA)
45Ω-20kΩ (<5mA)
0mΩ-20kΩ (automatic)
3. Accuracy:0.2%±2μΩ

4. Resolution:0.1μΩ

5. Operating temperature:-20～40℃

6. Environment humidity:≤80%RH,No condensation

7. Working power:AC220V

8. Volume:400×220×320mm

9. Weight:10kg

For more information , click this link to send us inquiry now !

Product pictures:

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 0

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 1

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 2

Our company :

Wuhan GDZX Power Equipment Co.,ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
What's more, our customers come from different countries like America, England, Peru , Malysia, Vietnam ,Singapore and so on.
Our main products are High voltage tester , Cable Fault Locator, Power Quality Analyzer, Standard Power source , Testing Transformer and so on.

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 3

Packaging & Delivery

1. Delivery within 8-15 work days
2. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
3. Experienced and professional logistic agent .

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 4

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 5

ZXR-10A 200mA Transformer Winding Resistance Tester AC220V 6
