Tip Function Electrical Power Calibrator Transducer Remote AC Sampling Apparatus

Tip Function Electrical Power Calibrator Transducer Remote AC Sampling Apparatus
Tip Function Electrical Power Calibrator Transducer Remote AC Sampling Apparatus

Large Image :  Tip Function Electrical Power Calibrator Transducer Remote AC Sampling Apparatus

Product Details:
Place of Origin: CHINA
Brand Name: GDZX
Certification: ISO9001
Model Number: ZX3030E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: carton
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detailed Product Description
Voltage: 25V、100V、250V、600V Current: 0.1A、1A、5A、25A
Accuracy: 0.05 Power Supply: 220V±10%
High Light:

calibration test bench

,

electric meter calibration equipment

Transducer Remote AC sampling apparatus Calibration Testing Source

Features

1. Using DSP digital signal generating and processing technology makes the measuring output stable and reliable

2. Integrated error 0.05 level (electric energy 0.1 level), high precision good anti-interference

3. Microcomputer management platform, capable of calibrating, transmitting, printing and data management.Specially equip with wireless receiver and emitter to enable remote calibration of AC sampling apparatus.

4. range of voltage current can be preset, and can be shifted automatically

5. large LCD display, tip function, on line help, massive information showing in one screen

6. Can output AC/DC voltage current, equip with standards of power, frequency, phase, power factor, DC voltage current, can display primary value and secondary value at the same time, auto-check the error, save and preview testing results.

7. can test 2~31th order harmonics

8. function of external software calibrating

9. great over-load capacity, can be with 1uFcapacitance (100V)

10. with voltage linkage protection, current limit protection, power amplifier self-closing function

11. going through over-load test, dumping test, misusing test, high temperature aging test make it reliable to use

12. with Germany standard carrying box, light and portable


Tip Function Electrical Power Calibrator Transducer Remote AC Sampling Apparatus 0

Technical Indicators

Item Index
Voltage AC range Basic range: 25V,100V,250V,600V
automatic range: 15V~600V
DC range Basic 100mV,25V,100V,250V,600V
automatic range: 15V~600V
Regulation range 0~130% UN
Regulation fineness 0.002%UN
Maximum output capacity ≥20VA/Phase
Fineness 0.05 (100mV: 0.1)
Current AC range Basic range: 0.1A,1A,5A,25A
automatic range: 0.05A~25A
DC range Basic range: 20µA,200µA,2mA,20mA,0.1A,1A,5A,25A
automatic range: 20µA~20mA & 0.1A~25A
Regulation range 0~130%IN(25A: 0~120%)
Regulation fineness 0.002%IN
Maximum output capacity ≥25VA/Phase
Accuracy 0.05
Frequency Regulation range 40HZ~70HZ
Regulation fineness 0.01HZ
Regulation accuracy ±0.01HZ
Phase Regulation range 0~359.99°
Regulation fineness 0.01°
Accuracy ±0.2°( rated output voltage current at full range)
Three phase power accuracy 0.05(reactive power: 0.2)
Three phase voltage symmetry Three phase four line 120°±0.2° Three phase three line 60°±0.2°
voltage current waveform distortion < 0.3%
Harmonic component 2~31 orders(when >11, only odd numbers can be set)
voltage current power stability ≤0.01%(1min)
Accuracy 0.01(0~±20mA,0~±5V)
Integrated error 0.05%
Weight 18kg
Dimension 432×428×175
Power supply 220V±10%
