Home > products > Lightning Arrester Test Equipment > ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time

Product Details

Place of Origin: Hubei, China

Brand Name: GDZX

Model Number: ZX-JS

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: $300.00 - $500.00 / Sets

Packaging Details: Carton or wooden box

Delivery Time: 7~10 work days

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability: 100 Set/Sets per Month

Get Best Price
Product Details
Highlight:

lightning arrester tester

,

leakage current test equipment

Product Name:
Zinc Oxide Lightning Arrester Discharge Counter Tester
Ambient Temperature:
-10℃~+50℃
Relative Humidity:
≤20~90%(at 40℃)
Discharge Test Voltage:
> 2kV
Dimension:
300x200x180mm
Weight:
6KG
Product Name:
Zinc Oxide Lightning Arrester Discharge Counter Tester
Ambient Temperature:
-10℃~+50℃
Relative Humidity:
≤20~90%(at 40℃)
Discharge Test Voltage:
> 2kV
Dimension:
300x200x180mm
Weight:
6KG
Product Description

Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time


Introduction


This instrument is used for discharge action logger inspection and verification of discharge counter in valve-type arrester including silicon carbide common valve type (FZ and FS), silicon carbide magnetic blow valve-type (FCZ and FCD) and zinc oxide arrester.


Work environment

1. Ambient temperature: -10ºC~+50ºC

2. Relative humidity: ≤20~90%(at 40ºC)

3. Atmospheric pressure:86~106kPa


Technical Parameters

Discharge test voltage > 2kV
Charge time < 1 minute
Power supply 220V±10%
Frequency 50±1Hz
Power < 30vA
Dimension 300x200x180mm
Weight 6KG


ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 0ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 1ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 2ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 3

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 4

Packaging & Shipping

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 5

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 6ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 7ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 8


Packaging & Shipping

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 7

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 10

Company Information

Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipmentIntegrating design , production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 11

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 12

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 13ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 14ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 15

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 16

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 17


ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 18

Our Services

Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 19

ZX-JS Zinc Oxide Lightning Surge Arrester Discharge Counter Tester Long Life Time 20




FAQ

1.Q: Are you trading company or manufacturer?
A: We are manufacturer.

We have R&D department, OEM& ODM services available.


2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.


3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.


4.Q: What is your term of payment?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 40% T/T in advance, balance before shipment.


5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, PayPal, Western Union, Money Gram, Cash etc.


6.Q: Will you provide OEM service?
A: OEM & ODM services available


7.Q: How long is the product warranty?
A: 1 year.
