High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector
High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector
video play

Large Image :  High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector

Product Details:
Place of Origin: China
Brand Name: GDZX
Certification: ISO9001
Model Number: ZXSF-1D
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: US $2579.00-4529.00/SET
Packaging Details: carton or wooden case
Delivery Time: 8-15 working days
Payment Terms: L/C, T/T
Supply Ability: 1200 sets/year
Detailed Product Description
Product Name: SF6 Gas Leak Detector Measuring Range: 0 ~ 999.9PPM
Resolution: 0.1ppm Repeatability: ± 0.1PPM
Probe Protection: Stainless Steel Sintered Filter Gas Flow Rate: Adjusted Automatically
Operating Voltage: 110 ~ 220VAC, AC And DC Working Temperature: Temperature: -25 ~ + 60 ℃
Storage Temperature Rating: -25 ~ + 70 ℃ Volume And Weight: 372*266.5*134.5 (mm), 3.5kg
High Light:

High Sensitivity SF6 Leak Detector

,

32 Bit ARM MCU SF6 Leak Detector

,

High Sensitivity SF6 Leak Detection Equipment

ZXSF-1D SF6 Gas Leak Detector

Product introduction

ZXSF-1D SF6 Gas Leak Detector is with high sensitivity, good stability, high speed, easy operation and large moving range. It rapidly detect SF6 breaker, GIS leakage point and yearly leakage rate qualitatively and quantitatively. It's a good device suitable for power supply department, installation and overhaul unit, power test institute.



The quantitative leak to infrared sensor at the core, high-precision sampling AD, speed ARMCPU, making the sample data is more real, more reliable. The instrument uses a color LCD touch-screen display, user-friendly appearance, easy to operate.



High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 0



Features

1. 4.3" TFT touch screen design;

2. 32-bit ARM MCU;

3. Separately designed air way and circuit;

4. Digital display of battery electric quantity;

5. Good repeatability, high response speed;

6. Automatic calibration of gradient;

7. Color LCD display;

8. Advanced probe protection function;

9. Anti-pollution, anti-disturbance;

10. High sensitivity, good stability;

11. Small, beautiful, easy to carry;

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 1



Technical Indicators
1. Measuring range: 0 ~ 999.9PPM
2. Accuracy: 1PPM (0 ~ 50PPM inside)
3. Resolution: 0.1ppm
4. Repeatability: ± 0.1PPM
5. Gas flow rate: adjusted automatically
6. Probe protection: stainless steel sintered filter
7. Operating voltage: 110 ~ 220VAC, AC and DC
8. Storage Temperature rating: -25 ~ + 70 ℃
9. Operating environment: Temperature: -25 ~ + 60 ℃
10. Lithium battery, AC/DC dual-use, automatic switching, protection against over-charging and over-discharging
11. Volume and weight: 372*266.5*134.5 (mm), 3.5kg



Product pictures

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 2High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 3



High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 4High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 5



PACKING AND SHIPPING
(1)We will ship products within 7-15 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.
If you need detailed specification, please feel free to contact us.High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 6





Company introduction
Wuhan GDZX Power Equipment Co.,Ltd.is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 7



High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 8



High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 9

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 10






High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 11High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 12High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 13




Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

High Sensitivity Portable 110 ~ 220VAC DC SF6 Gas Quantitative Leak Detector 14





FAQ:



1.Q: Are you trading company or manufacturer?
A: We are manufacturer.

We have R&D department, OEM& ODM services available.



2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.



3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.



4.Q: What is your term of payment?
A: Payment<=10000USD, 100% in advance. Payment>=10000USD, 30% T/T in advance, balance before shipment.



5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, PayPal, Western Union, Money Gram, Cash etc.



6.Q: Will you provide OEM service?
A: OEM & ODM services available



7.Q: How long is the product warranty?
A: 1 year.
