Product Details:
Payment & Shipping Terms:
|
| Model NO.: | GM-2500V | Output Voltage Error: | +/-5 % |
|---|---|---|---|
| Trademark: | GDZX | Warranty: | 1 Year |
| Operating Temperature And Humidity: | 0℃ ~ + 40℃ < 85%RH | Power Supply: | 12V Lithium Battery |
GM-2500V Adjustable High Voltage Digital Megohm Meter
Introduction
This instrument has high test voltage and strong output, and the measured object often has power frequency leakage or induction of high voltage interference electric energy, so for personal safety, the use of this instrument must first connect the safety grounding wire!
This instrument is designed and developed by our company to test the electrical insulation resistance characteristics of large high-voltage transformers, motor appliances, remote power cables or buried cables under the strong interference of high-voltage substations and power plants. It can also be used to measure electrical insulation resistance characteristics in a wide range of fields.
Features
1. Microcomputer control, menu operation, large-screen LCD dot matrix display, stable performance, intelligent instrument.
2. Strong anti-interference ability, suitable for measurement in strong electromagnetic interference environment.
3. There are four voltage output files: 250V, 500V, 1.0kV, 2.5kV.
4. Each high voltage can be adjusted continuously from zero.
5. Automatic measurement of R15, R60, R600, automatic calculation of absorption ratio, polarization index.
6. Strong load capacity, short circuit current about 5mA.
7. The maximum measuring range is 0 ~5TΩ, and the measuring range is automatically switched.
8. The analog bar pointer is combined with the digital display to visually indicate the trend of data change and accurate measurement results.
9. Display the test time at any time, and the buzzer automatically sounds every 15 seconds.
10. After measuring, the high pressure is automatically released, and the high pressure release time does not exceed 30 seconds.
11. Automatic measurement of ambient temperature, air humidity and the date and time of each test.
12. Can save 60 groups of measurement results, and the data can not be lost for 20 years.
13. Comes with RS232 serial interface, can communicate with computer data.
14.5 minutes If no operation is performed, the system automatically buzzes to shut down.
15. With comprehensive and perfect protection function, high reliability.
Technical parameters
| Rated test voltage | 250V 500V 1KV 2.5KV | |
| Measurement upper limit | 500GΩ 1TΩ 2TΩ 5TΩ | |
| Lower limit of measurement | 0.1MΩ | |
| Output voltage error | ±5% | |
| Short-circuit current | About 5mA | |
| Accuracy class | Level 5.0 | |
| Basic error in the lower half range | ±( 5%·Rx + 1d ) | |
| Basic error in the upper half range | ±( 10%·Rx + 2d ) | |
| High voltage display error | ±( 5%·Ux + 1d ) | |
| Temperature measurement error | ±0.5℃ | |
| Air humidity measurement error | ±2%RH | |
| Power supply | 12V lithium battery | |
| Battery life on a single charge | 10 DAR and 5 PI tests per day for 30 days | |
| Insulation resistance | > 500 MΩ (between test line and housing) | |
| Withstand voltage |
AC10.0kV 50Hz 1min (Between test line and housing) |
|
| Operating temperature and humidity | 0℃ ~ + 40℃ < 85%RH | |
| Storage temperature and humidity | - 20℃ ~ + 50℃ < 90%RH | |
| Overall dimension | 270(L)×240(W)×165(H) (mm) | |
| weight | ≈ 4.5kg | |
