ZXPD-400T local LED detector

Product Details

Place of Origin: china

Brand Name: GDZX

Certification: ISO9001

Model Number: ZXPD-400T

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $4900.00- $8700.00 / Sets

Packaging Details: export standard wooden box

Delivery Time: 8-15 work days

Payment Terms: L/C,T/T,Western Union,MoneyGram

Supply Ability: 1200/Sets per Year

Get Best Price
Product Details
Highlight:
Measurement Range:
0~70dBmV
Resolution:
1dB
Accuracy:
±1dB
Maximum Pulse Per Cycle:
1400
Measurement Band:
3~100MHz
Measurement Range:
0~70dBmV
Resolution:
1dB
Accuracy:
±1dB
Maximum Pulse Per Cycle:
1400
Measurement Band:
3~100MHz
Product Description

Introduction:

ZXPD-400T local LED detector,It can be widely used in the local discharge detection of high-voltage switch cabinets, ring cabinets, voltage/current transformers, transformers (including dry transformers), GIS, overhead lines, cables and other equipment in power systems.

ZXPD-400T local LED detector 0

Scope of application:

1. Used for ultrasonic and ground wave testing of switch cabinets.

Features:

1. The humanized human-machine interface is convenient for data management of different devices;

2. Built-in ultrasonic sensors and transient ground voltage (hereinafter referred to as TEV) sensors, which can be connected to external transformers, GIS, overhead lines, cables and other special sensors;

3. Non-invasive detection method is adopted, and there is no need to cut off power during the test, and no additional high-voltage source is required.

4. The test bandwidth range is 30kHz~2.0GHz, which is suitable for detection principles in various frequency bands;

5. The additional infrared thermal imager can convert this part of infrared radiation that is invisible to the naked eye on the surface of an object into a visible image. Infrared thermal imaging is not affected by visible light, and has the advantages of non-contact temperature measurement, smoke and mist penetration, and is very suitable for temperature detection of electrical equipment.

6. The image color and hot spot tracking and display functions displayed on the screen can be used to determine the heat and faulty locations in a preliminary manner, so as to confirm the problem efficiently and accurately.

Product parameters:

Earth radio wave parameters
Measurement range

0~70dBmV

Resolution

1dB

Accuracy

±1dB

Maximum pulse per cycle

1400

Measurement band

3~100MHz

Contact ultrasonic parameters
Measurement range

-6dBμV 至 68dBμV

Resolution

1dB

Accuracy

±1dB

Frequency range

20~200 kHz

hardware
shell

ABS

Host size

248*165*55(长*宽*厚,mm)

show 7-inch capacitive touch screen, resolution 1280*800
Sampling accuracy

12bit

Synchronization method Internal synchronization, external synchronization
Connector USB interface (both charger input) external sensor input interface, wifi, network port, Bluetooth
SD card Standard 16G~64G
Built-in battery 3.7V/5000mAh lithium battery
Working hours About 6 hours
charger

100~240VAC,50/60Hz

Use temperature

-35℃~50℃

humidity

30%~60%

Volume, weight

1.3kg
