Product Details
Place of Origin: CHINA
Brand Name: GDZX
Certification: ISO9001
Model Number: ZXHL-200A
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD$520.00 - $1,488.00 / Sets
Packaging Details: Packed in wooden case or carton
Delivery Time: 8-15 WORK DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1200 /Sets per Year
Item/Model: |
ZXHL-200A |
Measurement Range: |
1~1999μΩ |
Resolution: |
1μΩ |
DC Test Current (customizable): |
50A,100A,150A,200A |
Accuracy: |
±（0.5% Rd+2d） |
Relative Humidity: |
<=90% No Condensation |
Range: |
0~100mΩ(50A) 0~50mΩ(100A) |
Power: |
Electronic, 1000W |
Item/Model: |
ZXHL-200A |
Measurement Range: |
1~1999μΩ |
Resolution: |
1μΩ |
DC Test Current (customizable): |
50A,100A,150A,200A |
Accuracy: |
±（0.5% Rd+2d） |
Relative Humidity: |
<=90% No Condensation |
Range: |
0~100mΩ(50A) 0~50mΩ(100A) |
Power: |
Electronic, 1000W |
Wuhan GDZX Power Equipment Co.,Ltd OFFER YOU :
1: FACTORY DIRECT PRICE.
2: NICE QUALITY.
3: QUICK SHIPPING WITHIN 15 DAYS.
4: SMALL ORDER WELCOME..
5: ONLINE PAYMENT.
6: SUPPORT One year free warranty, three years quality assurance, lifetime maintenance.
7: AFTER SALES SERVICES 24/7
1. High current: For latest power supply technology, the tester can continuously output high current which overcomes the weakness of instantaneous current produced by pulsed power. It can effectively breakdown/puncture the oxide layer of the switches and then get precise results.
2. Strong anti-interference ability: The last number of test data will stably show in the LCD screen only with ±1d error even in strong Interference situation.
3. Long service life: All the precise resistances used in the tester can reduce the temperature’s impact on the measurement results and military connectors can enhance vibration resistance.
4. Convenience: Small size, light weight.
Parameters:
| Item/Model | ZXHL-100A | ZXHL-200A | ZXHL-300A | ZXHL-600A |
| Measurement range | 1~1999μΩ | |||
| Resolution | 1μΩ | |||
| DC Test current (customizable) | 100A | 50A,100A,150A,200A | 100A,200A,300A | 100A,200A,400A,600A |
| Accuracy | ±(0.5% rd+2d) | |||
| Working mode | Continuous | Continuous | Continuous |
100A:600S,200A:60S, 400A:10S,600A:10S |
| Display | Current & resistance:Three and a half digital display | |||
| Power supply | AC220V±10% 50Hz | |||
| Service conditions | Temperature -10℃~40℃, humidity:≤80%RH | |||
| Dimension | 300×280×210mm | 380*350*260mm | 380*350*260mm | 350×350×510 mm |
| N.W. | 6 KG | 5 KG | 10 KG | 30 KG |
