|Product Name:||Hand-held SF6 Gas Leak Detector||Measuring Method:||Mechanical Pump Style|
|Sensitivity Adjustment Level:||7 Levels||Ultimate Sensitivity:||<3g/year|
|Response Time:||Instantaneous||Operating Temperature:||30°to 125°F (0℃ To 52℃)|
|Power Supply:||3V DC;two "C" Cell Alkaline Batteries||Battery Life:||30 Hours|
|Size And Weight:||22.9*6.5*6.5cm; 560g|
Handheld SF6 Gas Leak Detector,
SAE J1627 SF6 Gas Leak Detector,
1S Reset SF6 Leak Detection Equipment
XP-1A Hand-held SF6 Gas Leak Detector is mainly applied for the leaking finding of equipment and container which are filled with the SF6 and other halogen gas in the ministry of water conservancy and electric power, the manufacturing engineering of electronic device, and the metallurgy of iron and steel, the petrochemical industry, the railway transportation, the mining industry, the extinguisher apartment and the atomic physics research institute.
1. Detecting SF6 gas detection of the power switch;
2. Detecting leakage of various HFC, CFC and HCFC refrigerants;
3. The high efficiency pump inside the probe can reduce the response time of the instrument;
4. No calibration is required and the warm-up time is short;
5. Leakage can be found even in a polluted atmosphere;
6. Ultra-sensitivity: At an annual leak rate of 4.6 g/year, it can still react to a very small amount of leakage;
7. LED leakage loss vector indicator light, there is a reset button on the probe handle, a large amount of refrigerant will not "poison" the probe;
8. The narrow and flexible stainless steel probe can detect difficult areas.
|Measuring Method||mechanical pump style|
|Flexible probe length||35.5cm|
|Leakage level indication||18 levels|
|Sensitivity adjustment level||7 levels|
|Mute key function||yes|
|battery test function||yes|
|Reset time||1 second|
|Warm up time||Approximately 2 Seconds|
|Operating temperature||30°to 125°F (0℃ to 52℃)|
|Power supply||3V DC; two "C" cell alkaline batteries|
|Battery life||30 hours|
|Sensing tip life||Approx. 20 hours|
|Certifited to||CE,SAE J1627|
1.Q: Are you trading company or manufacturer?
A: We are manufacturer.
We have R&D department, OEM& ODM services available.
2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.
3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.
4.Q: What is your term of payment?
A: Payment<=5000USD, 100% in advance. Payment>5000USD, 30% T/T in advance, balance before shipment.
5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, L/C.
6.Q: Will you provide OEM service?
A: OEM & ODM services available
7.Q: How long is the product warranty?
A: 1 year.
