DC24V Handheld Multifunction Process Calibrator For Site

Name: DC24V Handheld Multifunction Process Calibrator For Site
Brand: GDZX
SKU: ZXTX Series
Price: 1989.00 USD
Availability: InStock
Rating: 4.5 (146 reviews)

Large Image : DC24V Handheld Multifunction Process Calibrator For Site

Product Details:

Place of Origin:	China
Brand Name:	GDZX
Certification:	ISO9001
Model Number:	ZXTX Series

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	US $1989.00-$4236.00 /SET
Packaging Details:	Packing wooden case or carton
Delivery Time:	7-20 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram, D/A, D/P, WeChat, Paypal
Supply Ability:	1200sets/year

Contact Now

Detailed Product Description

Product Name:	Multifunction Process Calibrator	DC V:	0-60.000V (Upper Display+/-30V)
DC MA:	0-24.000mA(Upper Display+/-24mV)	DC MV:	-15.000mV-125.00mV
Frequency:	1.000Hz-99.999kHz	Resistance (4wires):	0.00Ohm-3200.00Ohm
High Light:	Handheld Multifunction Process Calibrator , DC24V Multifunction Process Calibrator , DC24V Handheld Multifunction Calibrator

DC 24V Handheld Multifunction Process Calibrator For Site

Product introduction

The ZXTX series multifunctional process Calibration instrument is a high precision hand-held signal measurement / output instrument, which can measure and output voltage, current, resistance, frequency, thermocouple at the same time. Various industrial process signals, such as thermal resistance, can be used to calibrate pressure transducers with external high precision intelligent pressure modules. It can replace current signal source, voltage signal source, resistance box, electronic potentiometer, frequency meter and other measuring and calibration instruments. Mainly used in industrial field signal calibration, fault diagnosis; also applicable to chemical, military and all kinds of research institutes, real Signal measurement and calibration in laboratory.

DC24V Handheld Multifunction Process Calibrator For Site 0

Features

1.Super strong protection function: waterproof grade IP67, arbitrary signal end misconnect 220 V automatic protection.

2.Measurement / output: voltage, current, frequency, resistance, in which current output supports active, passive.

3.The thermal resistance and thermocouple are simulated in the form of temperature.

4.Can simulate two-wire transmitter.

5.The accuracy was 0.02% ;0.05%.

6.Two isolated channels support synchronous measurement and output.

7.Can provide manual step, automatic step, 0-100% step and slope output function;

8.With white LED backlight, manual backlight adjustment and automatic power off function, suitable for field use.

9.Provide DC24V circuit power suppcalibration;ly for field debugging.

10.Unique automatic identification of three-wire, four-wire connection mode.

11.Support customer self,Band on-off test function.

12.Thermocouple measurement and output provide automatic and manual cold end temperature compensation.

13Can add new thermocouple, thermal resistance type according to customer needs.

Technical Indicators

(1)Measurement Index

Function	Range	Accuracy(% Reading+counts)
		ZXTX-2025	ZXTX-1825
DC V	0~60.000V(Upper Display ±30V)	0.02%+2	0.05%+2
DC mA	0-24.000mA(Upper Display ±24mV)	0.02%+2	0.05%+2
DC mV	-15.000mV~80.000mV	0.02%+2	0.05%+2
	80.00mV~125.00mV
Resistance (2 wires, 3wires)	0.00Ω~440.00Ω	0.15Ω	0.25Ω
	400..00Ω~3200.00Ω	1.0Ω	1.5Ω
Resistance (4wires)	0.00Ω~440.00Ω	0.1Ω	0.15Ω
	400..00Ω~3200.00Ω	0.5Ω	1.0Ω
Frequency	1.000Hz~99.999Hz	0.01%+1	0.02%+1
	1000.0Hz~9999.99Hz
	10.000kHz~99.999kHz
TC	J,K,T,E,R,S,B,N
RTD	Pt100,Pt1000, Cu50, Cu100

(2)Output Index

Function	Range	Accuracy(% Reading+counts)
		ZXTX-2025	ZXTX-1825
DC mA(Active/Passive)	0-24.000mA	0.02%+2	0.05%+2
DC V	0~10.000V	0.02%+2	0.05%+2
DC mV	-15.000mV~99.999mV	0.02%+2	0.05%+2
	100.00mV~125.00mV
Resistance	10.00Ω~440.00Ω	0.15Ω	0.25Ω
	400.0Ω~3200.0Ω	1.0Ω	1.5Ω
Frequency	0.20Hz~200.00Hz	0.01%+1	0.02%+1
	200.0Hz~2000.0Hz
	2.000kHz~20.000kHz
TC	J,K,T,E,R,S,B,N
RTD	Pt100,Pt1000, Cu50, Cu100

Test cases

Company introduction
Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.

Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

PACKING AND SHIPPING

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.
If you need detailed specification, please feel free to contact us.
