ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator

Name: ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator
Brand: Wuhan GDZX Power Equipment Co., Ltd
SKU: ZXHQ-T
Price: 50,558.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GDZX

Certification: ISO9001

Model Number: ZXHQ-T

Payment & Shipping Terms

Minimum Order Quantity: 1Set

Price: US $39208.00-$61909.00/Set

Packaging Details: Packing wooden case or carton

Delivery Time: 7-20 work days

Payment Terms: L/C,T/T,Western Union,MoneyGram,D/A,D/P,WeChat,Paypal

Supply Ability: 1200sets/year

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                Automatic Multi Transformer Verification Device, Intelligent Multi Transformer Verification Device, Intelligent Transformer Calibrator


Product Name:	High-speed Multi Transformer Verification Device	Temperature:	5 ℃ ~ 40 ℃
Power Frequency:	50Hz ± 0.5Hz	Power Supply Voltage:	220V ± 5V
Altitude:	<2500m	Relative Humidity:	<80% (25 ℃)
Impedance (W):	0.0001 ~ 60.0 Resolution: 0.0001	Current:	(1% -149%) In (In = 5A); (5% -149%) In (In = 1A)
Dial Indicator:	Level 1

Product Name:	High-speed Multi Transformer Verification Device
Temperature:	5 ℃ ~ 40 ℃
Power Frequency:	50Hz ± 0.5Hz
Power Supply Voltage:	220V ± 5V
Altitude:	<2500m
Relative Humidity:	<80% (25 ℃)
Impedance (W):	0.0001 ~ 60.0 Resolution: 0.0001
Current:	(1% -149%) In (In = 5A); (5% -149%) In (In = 1A)
Dial Indicator:	Level 1

Product Description

Intelligent Automatic High-speed Multi Transformer Verification Device,Transformer calibrator

Product introduction

ZXHQ-T High-speed transformer verification device is a new generation of transformer verification device developed by our company. The design idea of virtual instrument is adopted. The user only needs to operate the virtual instrument interface on the computer screen through the mouse and keyboard to input the transformer type, range, accuracy level, capacity, power factor and other parameters can complete automatic testing of current transformers and voltage transformers, as well as analysis, calculation and database management of test results, and can be printed according to user needs various records and certificates.

Features

1. The automatic mutual-inductor calibration platform adopts a single chip microcomputer to realize the functions of measurement, control and display.

2. With computer interface, improve the level of office automation and reduce the labor intensity.

3. Can have a large screen display, provide a friendly operation interface, and rich measurement information.

4. It can automatically realize the measurement of the transformer, and can automatically switch the current and voltage load box.

5. Possess good catching measures and be able to promptly inform users of wrong information.

6. This automatic transformer calibration station can reach level 2.

7. The transformation ratio of the standard transformer and the tested transformer does not have to be equal, as long as the rated primary voltage or rated primary current of the standard transformer is greater than or equal to the rated value of the tested transformer, it can be directly verified, which is more convenient to use.

Technical Indicators

1. Environmental conditions	1) Temperature: 5 ℃ ~ 40 ℃ 2) Relative humidity: <80% (25 ℃) 3) Altitude: <2500m 4) Power frequency: 50Hz ± 0.5Hz 5) Power supply voltage: 220V ± 5V
2. Measuring range	1) In-phase component (%): 0.0001 ~ 200.0 Resolution: 0.0001 2) Orthogonal component (minutes): 0.001 ~ 999.9 Resolution: 0.001 3) Impedance (W): 0.0001 ~ 60.0 Resolution: 0.0001 4) Admittance (ms): 0.0001 ~ 60.0 Resolution: 0.0001
3. Basic error	1) In-phase component: DX = ± (X × 2% + Y × 2% ± 2 words) 2) Quadrature component: DY = ± (X × 2% + Y × 2% ± 5 characters) "X" "Y"-display value of the instrument "5 words"-quantization error of the instrument 3) Dial indicator: level 1
4. Working range	1) Current: (1% -149%) In (In = 5A); (5% -149%) In (In = 1A)
5. Workload:	1) Current: To vs Tx <0.12Wcosj = 1
6. Polarity error indication	1) When the error is over 5% of the rated working current and the error exceeds 180%, there should be a polarity indication. Note: If it is more than 10% of the rated operating current, the polarity indication should not appear, indicating that the software is faulty, please do not increase the current, so as not to burn the instrument.
7. Variable ratio error indication	1) When the rated working current is more than 5%, and the error exceeds 30% but less than 180%, there should be a ratio error indication.
8. Insulation and withstand voltage test and description	1) Terminal Tx and ground terminal communicate 2) Both the K and D terminals are disconnected from the ground terminal 3) The power socket can withstand 1.5kV and 1min withstand voltage to the shell

Product pictures

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 0

Packaging & Shipping

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 1

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 2

Packaging & Shipping

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 6

Company Information

Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment. Integrating design , production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 7

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 8

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 9

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 12

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 13

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 14

Our Services

Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 15

ZXHQ-T Intelligent Automatic Multi Transformer Verification Device , Transformer Calibrator 16

FAQ

1.Q: Are you trading company or manufacturer?
A: We are manufacturer.

We have R&D department, OEM& ODM services available.

2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.

3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.

4.Q: What is your term of payment?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 40% T/T in advance, balance before shipment.

5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, PayPal, Western Union, Money Gram, Cash etc.

6.Q: Will you provide OEM service?
A: OEM & ODM services available

7.Q: How long is the product warranty?
A: 1 year.
