ZX-A10 TDR Cable Tester Fault Locator Test Distance 5m -40Km With LCD Display

ZX-A10 CABLE FAULT LOCATOR integrated embedded computer platform, Network Communications Service and USB communication system to improve the utilization of the device. The device consists 3 parts: main system, fault locator and cable line tester. It is used for cable fault location, cable line and depth test and daily maintenance of cable data. It can also be used for signal cable fault location for railway station and airport.

Features

ü Lithium-power supply affords the convenience of field tests.

ü 12.1 inch touch-screen and windows XP system.

ü USB communication interface. 5 sampling frequencies for options between 6.25 MHz to 100MHz

ü Auto search the fault point and display the distance, accurate up to 0.15m.

ü Freely compress or expanding waveform. Reference waveform close to standard waveform for reference.

ü 40G waveform data and on-site wiring diagrams for your reference.

ü Smart modular sampler to replace the on-site wiring, the sampling is totally isolated with high-voltage

Application

ü can be used for test cable fault for different voltage levels, different sections and different medium

ü Test open circuit, short circuit, low resistance and high resistance earth faults, flashing faults

ü can be used for testing signal cable fault for railway station, airport.

ü can be used for testing wave propagation speed of the cable which length is known.

ü can be used for testing the cable route and depth.

ü Display mode: 12.1 inch LCD (Windows XP)

ü Memory mode: Fixed and movable 20G/2G

ü Test methods: Low-voltage pulse method, impulse circuit method, impulse voltage method

ü Test distance: no less than 40km

ü The shortest testing distance (blind zone):5-10m

ü Location error: ±0.2m

Path analyzer technical specifications:

ü Signal frequency: 15KHz sine wave

ü Output power: Pomax≥100W

ü Output impedance: Zo=Zc

ü Vibration mode: incontinuous

ü Host Weight: 9.8Kg

ü Ambient temperature: -10℃~+40℃

ü Overall dimension: 180mm×300mm×400mm

ü Relative humidity: RH≤85%(25℃)

Impulse Generator

ü DC output: 32kV, continuous adjustable

ü external capacitance: 1~8 F

ü impact time: 1~6 seconds

ü maximum pulse energy: 400 ~ 1800J

ü maximum output current: 40mA

ü voltage indication error: + 2%

ü supply voltage: 220VAC 50Hz

ü ambient temperature: -10℃~ +50℃

ü volume: 380 x 260 x 260 mm
