Payment & Shipping Terms:
|Product Name::||Wireless High Voltage Phasing Tester||Accuracy Of Phase::||≤5°|
|Accuracy Of Frequency::||±0.1Hz||Walk Voltage measuring Range::||6kV-500kV(voltage Optional)|
|The Capacity Of The host batteries::||2500mAH, The Capacity Of The Launcher 350mAH||Working Environment::||-35℃~+45℃, Humidity≤95%RH|
|Weight And Size::||About 6kg; 57*30*15cm|
High Voltage Phasing Tester Wireless,
350mAH High Voltage Phasing Tester,
500kV High Voltage Phasing Tester
TAG-8000 Series Wireless High Voltage Phasing Tester
TAG-8000 Series Wireless High Voltage Phasing Tester is used for grid connection or ring network nuclear phase of two high voltage lines. The instrument can upgrade the function of remote nuclear phase. The instrument is suitable for live working of 6kV ~ 500kV (voltage optional) AC transmission line and secondary side, and has the function of high-voltage power inspection.
The instrument adopts wireless transmission technology, which is safe, reliable and easy to use, and overcomes many shortcomings of wired phase tester.
1.The maximum transmission vision distance between launcherand host:about 100M.
2. Human voice prompt operation steps and measurement results.
3. Display the phase difference, frequency, phase diagram, in-phase and out-of-phase results on the color creen(size: 320*240) at the same time.
4. Without operation in hour, shutdown automatic.
5. Both host and launcher can built-in rechargeable lithium battery,and can Disassembly and replacement.
|1. Accuracy of phase:||≤5°|
|2. Accuracy of frequency:||±0.1Hz|
|3. Walk Voltage measuring range:||6kV-500kV(voltage optional)|
|4. The capacity of the host batteries:||2500mAH,The capacity of the launcher 350mAH|
|5. leakage current in high voltage <10uA|
|6. The power of the launcher <0.1W,The power of the host <0.3W|
|7. Working environment:||-35℃~+45℃ Humidity≤95%RH|
|8. Storing environment:||-40℃~+55℃ Humidity≤95%RH|
PACKING AND SHIPPING
(1)We will ship products within 7-15 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.
If you need detailed specification, please feel free to contact us.
