Product Details
Place of Origin: China
Brand Name: GDZX
Certification: ISO9001
Model Number: ZX-A30
Payment & Shipping Terms
Minimum Order Quantity: 1Set
Packaging Details: Packing wooden case or carton
Delivery Time: 7-20 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/A, D/P, WeChat, Paypal
Supply Ability: 1200sets/year
Product Name: |
Intelligent Cable Fault Test System |
Temperature: |
-20℃～﹢40℃ |
Relative Humidity: |
≤80% |
Signal Frequency: |
Sine-wave 15KHz |
Output Power: |
Pomax ≥100W |
Output Impedance: |
Zo=Zc (Cable Characteristic Impedance) |
Vibrating Mode: |
Non-continuous |
Host Weight: |
6.2Kg |
Host Dimension: |
180mm×300mm×400mm |
Resolution: |
V/fm,V Is Transmitting Velocity M/μs；software Cursor Is 0.10m. |
Test Distance: |
No Less Than 60Km |
Product Name: |
Intelligent Cable Fault Test System |
Temperature: |
-20℃～﹢40℃ |
Relative Humidity: |
≤80% |
Signal Frequency: |
Sine-wave 15KHz |
Output Power: |
Pomax ≥100W |
Output Impedance: |
Zo=Zc (Cable Characteristic Impedance) |
Vibrating Mode: |
Non-continuous |
Host Weight: |
6.2Kg |
Host Dimension: |
180mm×300mm×400mm |
Resolution: |
V/fm,V Is Transmitting Velocity M/μs；software Cursor Is 0.10m. |
Test Distance: |
No Less Than 60Km |
35KV 60Km Full Intelligent Multiple Pulse Power Cable Fault Locator
Product introduction
ZX-A30 Full Intelligent Multiple Pulse Cable Fault Locator is networking cable fault test platform based on embedded computer platform. It integrates USB communication technology, touch-screen technology and 3G communication technology and this greatly improved the performance of the instrument in practice and it is easy to operate.
Features
Technical Indicators
| 1. Can test cable fault at different voltage levels below 35KV. Can test cable fault of different cable sections, different dielectric and different cable materials. Can test open-circuit cable fault, short-circuit cable fault, low-resistance cable fault, high-resistance leakage cable fault and high-resistance flash-over cable fault. | |
| 2. Test all faults of railway communication control cable, streetlight cable and airport signal cable. | |
| 3. Test wave transmitting velocity in any cable of known length. | |
| 4. Can test buried route and depth of power cable. | |
| 5.Display mode | 12.1in industrial LCD touch screen (Windows XP platform) |
| 6. Test method | LV impulse method, impulse HV flash-over method, multiple pulse method |
| 7. Storage | 8G |
| 8. Test distance | no less than 60Km |
| 9. Operate via Touch pen and mouse | |
| 10. Min. test distance (non-detection area) | 0-5m or without |
| 11. Locating error | ±0.2m |
| 12. Test error | system error is no ore than ±1% |
| 13. Multiple pulse generator | Impulse voltage ≤40KV |
| 14. Resolution | V/fm,V is transmitting velocity m/μs；software cursor is 0.10m. |
| 15. Sampling frequency | 6.25MHz,12.5MHz,25MHz,50MHz,100MHz (Adaptive pulse width). |
| 16. Power source and power consumption | AC 220V±10%, power ≤15W, DC 12V(7AH),power≤20W |
| 17. Standby time | continuous working 6 hours |
|
18.Host weight: Dimension: |
6.2Kg 180mm×300mm×400mm |
|
19. Temperature
|
-20℃～﹢40℃ Relative humidity:≤80% |
|
20. Management
|
Cable route and distribution map. All data of cable which is in user’s management region, including cable distribution map, number, initial position, buried depth and date, cable medium, connect position, record of fault, fault reason, technical test report, cable test record etc. |
| 21. Signal frequency | sine-wave 15KHz, Output power: Pomax ≥100W |
| 22. Output impedance | Zo=Zc (Cable characteristic impedance) |
| 23. Vibrating mode | non-continuous |
Company introduction
Wuhan GDZX Power Equipment Co.,Ltd.is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.
PACKING AND SHIPPING
(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.
If you need detailed specification, please feel free to contact us.
