Product Details
Place of Origin: CHINA
Brand Name: GDZX
Certification: ISO
Model Number: ZX-3125
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: $500.00 - $1,000.00 / Pieces
Packaging Details: CARTON
Delivery Time: 2000 Piece/Pieces per Month
Payment Terms: L/C, T/T, Western Union, MoneyGram
Output U: |
500V 1000V 2500V 5000V |
Measuring Range: |
0～1000GΩ |
Max Error: |
10% |
Power: |
14.8V Li-Battery |
Type: |
Resistance Box, Meter Box |
Output U: |
500V 1000V 2500V 5000V |
Measuring Range: |
0～1000GΩ |
Max Error: |
10% |
Power: |
14.8V Li-Battery |
Type: |
Resistance Box, Meter Box |
Smart Megger 5000V Insulation Resistance DAR PI Tester
Features
1. Wide range of measuring voltage, Test up to 1000GΩ (Max 2000GΩ) insulation resistance
2. Three and a half bit LCD digital display of resistance value
3. Automatically shift resistance measuring range
4. Environment temperature can be measured
5. Self-clocking function, short buzz every 15 seconds
6. Auto calculate and save R15S, R60S, R600S, DAR PI value
7. Output short-circuit current larger than 5mA (meet fast charging request to capacitive load)
8. Strong anti-interference ability, stable and reliable reading
9. Perfect protection, safe for operation
10. Powered by rechargeable Li-battery, auto power off when battery energy is not enough
| Rated voltage | 500V | 1000V | 2500V | 5000V | |||||
| Working voltage | Rated voltage×(1±10%) | ||||||||
| Measuring range | 0~100GΩ | 0~200GΩ | 0.001~500GΩ | 0.001~1000GΩ | |||||
| Max error:±10%RDG+1d (max display value: 1999) | |||||||||
| Short circuit output current | ≥1.5mA | ≥1.5mA | ≥5mA | ≥5mA | |||||
| absorption ratio, polarization index | Measuring range:0.1～19.99, max error:±2%RDG+1d | ||||||||
| Entire Power dissipation | ≤10W | ||||||||
| Operation temperature and humidity | 0℃～40℃; ≤ 85 % RH | ||||||||
| Withstand | AC2.5kV 50HZ 1min | ||||||||
| Working Power supply | 14.8V(2.2Ah) rechargeable Li-battery | ||||||||
| Charging supply | AC220V,50 HZ, (±10 %) | ||||||||
| Size and weight | 270mm(L)×210mm(W)×100mm(D) 2kg | ||||||||
