Wuhan GDZX Power Equipment Co., Ltd sales@gdzxdl.com 86--17362949750
Product Details
Place of Origin: CHINA
Brand Name: GDZX
Certification: ISO9001
Model Number: ETCR
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 320 USD
Packaging Details: carton
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500pcs/month
Brand: |
GDZX |
Resistance Range: |
0.01-200Ω (refer To The Selection Table) |
Warranty: |
1 Year |
Data Storage: |
99 Groups |
Working Temperature And Humidity: |
-20℃-55℃;20%RH-90%RH |
Structural Features: |
Clamp CT |
Single Measurement Time: |
0.5s |
Resistance Measurement Frequency: |
>1KHz |
Frequency Of Measured Current: |
50/60Hz Automatic |
Clamp Table Size: |
285*85*56mm³ |
Brand: |
GDZX |
Resistance Range: |
0.01-200Ω (refer To The Selection Table) |
Warranty: |
1 Year |
Data Storage: |
99 Groups |
Working Temperature And Humidity: |
-20℃-55℃;20%RH-90%RH |
Structural Features: |
Clamp CT |
Single Measurement Time: |
0.5s |
Resistance Measurement Frequency: |
>1KHz |
Frequency Of Measured Current: |
50/60Hz Automatic |
Clamp Table Size: |
285*85*56mm³ |
ETCR Series Earth Clamp Meter
Product Introduction :
ETCR series Earth Clamp Meter is widely used in the grounding resistance measurement of electric power, telecommunications, meteorology, oilfield, construction and the industrial and electrical equipment.
The measurement does not require disconnecting the grounding wire, need no auxiliary electrode. It is safe, fast and simple in use. It equips long jaws or round jaws. Long jaw is particularly suitable for the occasion of grounding with the flat steel. It also be able to measure the leakage current and the neutral current in the grounding system.
For more information , click this link to send us inquiry now !
1. step-up transformer capacity 1.5 kVA
2. rate of voltage rise
0.5 kV/s,1kV/s ,2.0kV/s,3.0kV/s , 5.0kV/s five gears
3. output voltage 0~80 kV
4. aberration rate of power supply <1%
5. display mode Big LCD display Chinese characters
6. electrode gap standard 2.5 mm
7. boundary dimension 409 mm×393 mm×388 mm
8. Instrument weight 29 kg;
service condition
1. environment temperature 0~40℃
2. relative humidity ≤85%
3. working power supply AC 220V ± 10%
4. supply frequency 50 /60± 5 H
5. power consumption <200 W
Product Atlas
Our company :
Wuhan GDZX Power Equipment Co.,ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
What's more, our customers come from different countries like America, England, Peru , Malysia, Vietnam ,Singapore and so on.
Our main products are High voltage tester , Cable Fault Locator, Power Quality Analyzer, Standard Power source , Testing Transformer and so on.
Packaging & Delivery
1. Delivery within 8-15 work days
2. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
3. Experienced and professional logistic agent .
