ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit

Name: ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit
Brand: Wuhan GDZX Power Equipment Co., Ltd
SKU: ZX-600
Price: 5.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: GDZX

Certification: ISO9001

Model Number: ZX-600

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $2,998.00 - $9,999.00 / Sets

Packaging Details: Packed in wooden case or carton

Delivery Time: 8-15 work days

Payment Terms: L/C,T/T,Western Union,MoneyGram

Supply Ability: 1000 Piece/Pieces per Month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                protection relay test equipment, protective relay tester


Brand:	GDZX	Auxiliary DC Output:	110V/220V DC (can Switch)
Switch Input:	8 Channels,10-250VDC Or Idle Contact, Auto-identifying, No Polarity	Screen:	8.4” 1024×768
Power Supply:	AC：220V±15% Frequency: 50Hz±10Hz	Dimension:	360 ×200 ×415 （mm）
Weight:	16.8Kg

Brand:	GDZX
Auxiliary DC Output:	110V/220V DC (can Switch)
Switch Input:	8 Channels,10-250VDC Or Idle Contact, Auto-identifying, No Polarity
Screen:	8.4” 1024×768
Power Supply:	AC：220V±15% Frequency: 50Hz±10Hz
Dimension:	360 ×200 ×415 （mm）
Weight:	16.8Kg

Product Description

Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit

PLEASE NOTE :

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 0

Wuhan GDZX Power Equipment Co.,Ltd OFFER YOU :

1: FACTORY DIRECT PRICE.
2: NICE QUALITY.
3: QUICK SHIPPING WITHIN 15 DAYS.
4: SMALL ORDER WELCOME..
5: ONLINE PAYMENT.
6: SUPPORT One year free warranty, three years quality assurance, lifetime maintenance.
7: AFTER SALES SERVICES 24/7
8. Respect every customer .

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 1

FEATURES:

1． Integrated high precision analog signal output source (accuracy: 0.05), no need external standard power source

2． Simultaneously measure voltage in 6 channels and current in 6 channels, auto release evaluation conclusion

3． Applies to traditional transformer input type, electronic transformer input type, mixed input type and other MU types

4． Full functions (accuracy, harmonic, transient error, synchronism, protocol, rated time delay, parallel/split logic, pressure

5． Built in auxiliary DC output, can shift between 110v and 220v

6． built in IPC work independently, or connect with external PC to operate

7． Reasonable heat radiation and hardware protection, over current/over temp/ short circuit protection, alarm function

Product parameters:

AC voltage source	6×120V, resolution: 100μV, maximum output power: 40VA/phase	Accuracy:0.05%
AC current source	6×20A, resolution: 25μA, maximum output power: 120VA/phase	Accuracy: 0.05%
DC voltage source	6×170V, resolution:100μV, maximum output power: 30VA/phase	Accuracy: 0.1%
DC current source	6×10A, resolution:25μA, maximum output power:60VA/phase	Accuracy:0.1%
Output frequency	0~2500Hz, resolution: 1mHz	Accuracy: 0.001Hz
Output phase	0~359.999°, resolution: 0.001°	Accuracy: 0.05°
Output harmonic	DC component, 2~20 order harmonic
Current voltage synchronization		＜5μs
Auxiliary DC output	110V/220V DC (can switch)
Small signal output	12×(0~7.07VAC/0~10VDC), resolution: 1mV	Amplitude accuracy: 0.05%
		phase accuracy:0.05°
		Frequency accuracy:0.001Hz
Optical Ethernet interface	6 pairs×100Mbits/s,SC,multi-mode,1310nm;	Sending dispersion: <0.1μs Receiving time accuracy: <25ns Maximum output flow: >95M
Optical Ethernet interface	IEC61850-9-1/2/LE,Goose,IEEE-1588	1588 time synchronization accuracy:<80ns
Optical serial interface	5pairs×(2~10Mbits/s, SC, multi-mode, 850nm；	Sending dispersion:<0.1μs
Optical serial interface	IEC60044-7/8,FT3; support Manchester code or asynchronous serial port transmission method	Receiving time accuracy:<25ns
Synchronous interface	Built in GPS;1 pair×IRIG-B/PPS optical port, SC, multi-mode, 850nm	Accuracy:<1μs
Electrical Ethernet interface	1pcs, RJ-45,100Mbits/s
Switch input	8 channels,10-250VDC or idle contact, auto-identifying, no polarity
Switch output	8 channels, idle contact/fast output, AC/DC breaking capability:0.5A, 250V	Fast output time:<10μs
Screen	8.4” 1024×768
Power supply	AC:220V±15% frequency: 50Hz±10Hz
Dimension	360 ×200 ×415 (mm)	Weight 16.8Kg

Should we can help you in price ,quality & delivery , pls feel free to contact me directly .

Your inquiry will be taken seriously .

Packaging & Shipping

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 2

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 3

Packaging & Shipping

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 7

Company Information

Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment. Integrating design , production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 8

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 9

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 10

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 13

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 14

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 15

Our Services

Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 16

ZX-600 Optical Digital Signal Relay Protection Tester Smart Terminal Merging Unit 17

FAQ

1.Q: Are you trading company or manufacturer?
A: We are manufacturer.

We have R&D department, OEM& ODM services available.

2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.

3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.

4.Q: What is your term of payment?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 40% T/T in advance, balance before shipment.

5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, PayPal, Western Union, Money Gram, Cash etc.

6.Q: Will you provide OEM service?
A: OEM & ODM services available

7.Q: How long is the product warranty?
A: 1 year.
