Hot Sell Portable Three Phase Energy Meter Calibrator Power Quality Analyzer

ZXDN-3A Three Phase Energy Meter Calibrator Power Quality Analyzer is our company's development, development of the collection of electric parameters measurement, electricity meter calibration, wiring judgment as one of the high-precision testing instruments. The instrument is equipped with voltage transformer and current transformer with high precision and high linearity, so that the instrument can measure all kinds of parameters with high accuracy. At the same time, it is equipped with clamp current transformer, which makes the field wiring simple and can be directly connected without disconnecting the current loop.

ZXDN-3A Three Phase Energy Meter Calibrator Power Quality Analyzer uses large screen color LCD as a display, full Chinese graphical operation interface and equipped with Chinese prompt information, multi-parameter display LCD display interface, man-machine dialogue interface friendly, vector diagram display and wiring judgment to check the correctness of the circuit provides a reliable basis. Full touch conductive silicone keyboard operation mode, good handling, easy to learn. The instrument built-in large capacity power loss data memory, can save the on-site calibration data, can store 1000 groups of on-site calibration results, can provide background microcomputer management software, upload the results to the computer, microcomputer management.

The instrument is made of engineering plastic shell designed and moulded independently by our company, with beautiful appearance and practical application. Field test is easy to operate.

• 1. High precision measuring instrument, which can be used for energy meter calibration, electric parameter test and the detection of the power quality problems such as wave distortion, voltage fluctuation and three-phase unbalance

• 2. Real load live test the integrated error of metering equipment, without power off, without changing the metering circuit, or opening the metering device.

• 3. Accurately measure a variety of electrical parameters, such as voltage, current, active power, reactive power, phase angle, power factor, frequency, etc.

• 4. Display the vector diagram of the measured voltage and current, by which users can judge if the metering device wiring is correct or not, can discriminate 48 kinds of wire connecting under three phases three wire connection mode, and can auto calculate electric quantity compensation.

• 5. The current circuit can be measured using clip on transformer without disconnecting current loop

• 6. Check voltmeter, ampere meter, power meter, phase meter and other indicators as well as three-phase three wire, three-phase four wire, single phase 1A, 5A all kinds of active and reactive power meter.

• 7. Photoelectric, manual, pulse and other methods for energy meter calibration

• 8. Measurement and analysis of the AC power quality from the utility grid to client can be easily done, including frequency deviation, voltage deviation, voltage fluctuations, flicker, three-phase voltage unbalance factor and harmonic.

• 9. Display single-phase voltage current waveform, also display 3-phase voltage and current waveform

• 10. The load fluctuation monitoring: measurement and analysis of power quality fluctuations caused by different running of all kinds of electric equipment to the utility grid, auto recording of electric power parameters.

• 11. Dynamic monitoring of power equipment adjustment and operation

• 12. Measure and analyze the dynamic parameters of reactive power compensation and filtering devices in the power system, and make quantitative evaluation of its features and technical specifications.

• 13. Calendar and real clock function, data automatically save during testing and can upload to computer

• 14. Large LCD display and user-friendly interface

• 15. Small size, light weight, easy to carry, suitable for on site testing or measurement in laboratory.

                                                     For more information , click this link to send us inquiry now !

Technical indicators :

Our company :

Wuhan GDZX Power Equipment Co.,ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
What's more, our customers come from different countries like America, England, Peru , Malysia, Vietnam ,Singapore and so on.
Our main products are High voltage tester , Cable Fault Locator, Power Quality Analyzer, Standard Power source , Testing Transformer and so on.

Packaging & Delivery

1. Delivery within 8-15 work days
2. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
3. Experienced and professional logistic agent .
