ZX-CH single-phase capacitance and inductance tester

Name: ZX-CH single-phase capacitance and inductance tester
Brand: Wuhan GDZX Power Equipment Co., Ltd
SKU: ZX-CH
Price: 2,150.00 USD
Availability: InStock

Product Details

Place of Origin: china

Brand Name: GDZX

Certification: ISO9001

Model Number: ZX-CH

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $1500.00- $2800.00 / Sets

Packaging Details: export standard wooden box

Delivery Time: 8-15 work days

Payment Terms: MoneyGram,Western Union,T/T,L/C

Supply Ability: 1200/Sets per Year

Get Best Price

Product Details

Product Description

Product Details

Highlight:

Measure Voltage:	AC25V±10%，50Hz AC1.25V±10%，50Hz 25VA	Resolution:	4-digit Valid Number
Host Size:	320mm×260mm×135mm	Host Weight:	4.8kg
Ambient Temperature:	－10℃～﹢50℃	Ambient Humidity:	≤85℅RH, No Condensation
Working Power Supply:	AC220V ±10%

Measure Voltage:	AC25V±10%，50Hz AC1.25V±10%，50Hz 25VA
Resolution:	4-digit Valid Number
Host Size:	320mm×260mm×135mm
Host Weight:	4.8kg
Ambient Temperature:	－10℃～﹢50℃
Ambient Humidity:	≤85℅RH, No Condensation
Working Power Supply:	AC220V ±10%

Product Description

Introduction:

ZX-CH single-phase capacity and inductance tester is an important equipment to meet the reactive balance of the power system. The complete set of reactive power compensation devices are invested in the distribution network in large quantities to balance the system's active and reactive power in real time. The reactive compensation device should meet the requirements of automatic tracking and real-time compensation, which inevitably requires frequent injection and cutting of the reactive compensation capacitor bank. The casting and cutting operations of the capacitor bank will cause overcurrent and overvoltage impacts, causing capacitor damage. In order to ensure the reliability of the equipment, capacitor defects are discovered early and the failure is avoided, regular inspection is required.Capacitor inductance testers are specially used for the measurement of capacitors and reactors in reactive compensation systems. The instrument adopts advanced measurement principles and four-end measurement technology to accurately measure groups of parallel capacitors and various reactors.

Features:

1. The instrument can complete single capacitor measurements of single-phase or three-phase parallel capacitor banks without disassembly.

2. The instrument also has inductance, resistance and current measurement functions.

3. The instrument has complete overcurrent protection function.

4. Adopt an 8.0-inch touch screen, easy to operate.

5. Built-in large-capacity non-volatile memory, which can store 200 sets of data.

6. Built-in high-speed micro thermal printer, which can print measurement data.

7. Built-in high-precision clock to display time in real time.

8. The instrument has USB disk storage function.

Product parameters:

Capacitance range	0.1uF～6800uF	Accuracy	±(读数1%+0.01uF)
Inductance range	100uH～20H	Accuracy	±(读数3%+0.01mH)
Current range	5mA～20A	Accuracy	±(读数3%+0.1mA)
Resistance range	50mΩ～20kΩ	Accuracy	±(读数3%+1mΩ)
Measure voltage	AC25V±10%,50Hz AC1.25V±10%,50Hz 25VA
Resolution	4-digit valid number
Host size	320mm×260mm×135mm
Host weight	4.8kg
Ambient temperature	－10℃～﹢50℃
Ambient humidity	≤85℅RH, no condensation
Working power supply	AC220V ±10%

Product Pictures:

ZX-CH single-phase capacitance and inductance tester 0

ZX-CH single-phase capacitance and inductance tester 2

Packaging & Shipping

ZX-CH single-phase capacitance and inductance tester 5

ZX-CH single-phase capacitance and inductance tester 6

Packaging & Shipping

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.

ZX-CH single-phase capacitance and inductance tester 10

Company Information

Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment. Integrating design , production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.

ZX-CH single-phase capacitance and inductance tester 11

ZX-CH single-phase capacitance and inductance tester 12

ZX-CH single-phase capacitance and inductance tester 13

ZX-CH single-phase capacitance and inductance tester 16

ZX-CH single-phase capacitance and inductance tester 17

ZX-CH single-phase capacitance and inductance tester 18

Our Services

Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* The contract and the technical agreement to sign by both parties.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user’s questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others.
Warranty
* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.
* Our products are guaranteed with one year warranty and life-long tech support.
* Provide solutions within 24 hours when there is problems feedback from customer.

ZX-CH single-phase capacitance and inductance tester 19

ZX-CH single-phase capacitance and inductance tester 20

FAQ

1.Q: Are you trading company or manufacturer?
A: We are manufacturer.

We have R&D department, OEM& ODM services available.

2.Q: How long is your delivery time?
A: We usually arrange shipment within 5-7 working days after checking the payment. However, for example, the delivery time of the complete set of test devices will be a little longer, which needs to be checked in real time.

3.Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample, but not for free; you need pay charge and the cost of freight.

4.Q: What is your term of payment?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 40% T/T in advance, balance before shipment.

5.Q: What is the payment method?
A: We can accept Bank Transfer, T/T, PayPal, Western Union, Money Gram, Cash etc.

6.Q: Will you provide OEM service?
A: OEM & ODM services available

7.Q: How long is the product warranty?
A: 1 year.
