ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision

Name: ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision
Brand: Wuhan GDZX Power Equipment Co., Ltd
SKU: ZXR-1A
Price: 539 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: GDZX

Certification: ISO9001

Model Number: ZXR-1A

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 539 USD

Packaging Details: carton

Payment Terms: L/C,T/T,Western Union,MoneyGram

Supply Ability: 500pcs/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                High Precision Dc Winding Resistance Test, 220V Transformer Winding Resistance Tester, 15W Transformer Winding Resistance Tester


Temperature:	0℃~40℃	Measuring Range:	1mΩ~20mΩ;20~200mΩ;0.2~2Ω;2~20Ω;20~200Ω;200Ω~2kΩ
Measurement Accuracy:	0.5	Warranty:	1 Year
Resolution:	1μΩ	Constant Current Source:	1A(1uΩ~2Ω),0.1A(2Ω~20Ω),0.01A(20Ω~200Ω),0.001A(200Ω~2000Ω)
Ammeter Display Range:	0.10A~1.00A	Operating Voltage:	DC:11V~14V AC:220V
Power Consumption:	≤15W	Volume And Weight:	335275175mm/2.8kg

Temperature:	0℃~40℃
Measuring Range:	1mΩ~20mΩ;20~200mΩ;0.2~2Ω;2~20Ω;20~200Ω;200Ω~2kΩ
Measurement Accuracy:	0.5
Warranty:	1 Year
Resolution:	1μΩ
Constant Current Source:	1A(1uΩ~2Ω),0.1A(2Ω~20Ω),0.01A(20Ω~200Ω),0.001A(200Ω~2000Ω)
Ammeter Display Range:	0.10A~1.00A
Operating Voltage:	DC:11V~14V AC:220V
Power Consumption:	≤15W
Volume And Weight:	335275175mm/2.8kg

Product Description

Transformer Winding Resistance Meter DC Tester

ZXR-1ATransformer Winding Resistance Tester

Product Introduction :

This instrument is a high-precision regeneration product used to replace DC single/double bridge. Equipped with advanced switch power supply technology, the measurement speed of the instrument is faster a hundred times than that of the bridge. Using four and half bits LCD to display the measurement results and three and half bits LCD to display ambient temperature or test current value, it overcomes the shortcoming of other similar products that it is difficult to read value from the LED display in the sun and possesses automatic arc suppression function. The instrument is characterized by fast test speed, high precision, intuitive display, strong anti-interference ability, small size, low power consumption, stable and reliable test data. Built-in rechargeable battery pack (12V) and AC/DC dual-use, the instrument is very convenient for on-site and field test.

Main characteristics:

Fast test: The maximum output charge current of the instrument is up to 1A. When measuring it can effectively compensate current inertial for large inductor and accelerate core saturation, thereby reduced the charging time and increased test speed. Its test speed is faster hundreds of times than the traditional single instrument and double bridge.
High accuracy: The application of advanced four-terminal measurement and constant current source technology to the instrument makes the inductive load charging current hold a relatively stable value. Base on that, and the instrument with stable anti-sense capability and strong anti-interference characteristics can ensure the accuracy of measurement. And the use of imported high-quality components not only improves the measurement accuracy, but also makes the instrument have good repeatability.
Wide measurement range: resistance measurement range 1μΩ ~ 2KΩ, wide range.
AC and DC power supply: Attached rechargeable battery, the instrument can use AC and DC power supply. Portable design, it is easy to carry and use.

Technical indicators:

1.Temperature:0℃~40℃ Humidity:≤85%RH
2.Measuring range:1mΩ~20mΩ;20~200mΩ;0.2~2Ω;2~20Ω;20~20Ω;200Ω~2kΩ
3.measurement accuracy:0.5 Resolution:1μΩ
4.constant current source:1A(1uΩ~2Ω),0.1A(2Ω~20Ω),0.01A(20Ω~200Ω),0.001A(200Ω~2000Ω)
5.Ammeter display range:0.10A~1.00A
6.Operating Voltage: DC:11V~14V AC:220V Power consumption:≤15W
7.Volume and weight:335×275×175mm/2.8kg

ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision 0

ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision 3

Packaging & Shipping

ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision 4

ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision 5

Packaging & Shipping

(1)We will ship products within 5-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.
(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.
(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.
(5)After shipping, we will remain attentive till goods well received.

ZXR-1A Transformer Winding Resistance Meter DC Tester High Precision 9

Company Information

Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment. Integrating design , production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
