Home > products > Earth Insulation Tester > LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester

LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester

Product Details

Place of Origin: CHINA

Brand Name: GDZX

Certification: ISO9001

Model Number: LBQ-II

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 135 USD/set

Packaging Details: wooden case

Delivery Time: 7

Supply Ability: 100 Piece/Pieces per Month

Get Best Price
Product Details
Highlight:

500mA Leakage Current Tester

,

AC380V Leakage Current Tester

,

AC220V Electrical Leakage Tester

Rated Voltage:
AC220V、380V
Limited Test Voltage:
Below AC250V
Leakage Current Range:
15、30、50、75、100、150、200、250、300、500mA
Leakage Operating Time Range:
0-799ms
Leakage Current Accuracy:
1 Class
Operating Time Display Accuracy:
0.5%(±2d)
Working Environment Temperature:
0℃-40℃
Working Environment Relative Humidity:
<85%
Outside Dimension:
195*101*42mm
Warranty:
1 Year
Rated Voltage:
AC220V、380V
Limited Test Voltage:
Below AC250V
Leakage Current Range:
15、30、50、75、100、150、200、250、300、500mA
Leakage Operating Time Range:
0-799ms
Leakage Current Accuracy:
1 Class
Operating Time Display Accuracy:
0.5%(±2d)
Working Environment Temperature:
0℃-40℃
Working Environment Relative Humidity:
<85%
Outside Dimension:
195*101*42mm
Warranty:
1 Year
Product Description

AC220V 380V 500mA Handheld Single Phase Three Phase Leakage Protector Tester




Product Introduction :



Leakage Protector Tester is well designed and manufactured for online measuring the leakage operating current, leakage non-operating current, leakage operating time of the leakage protector; adopt 16 characters blue display, it is convenient and intuitive. The range of leakage current is 0~500mA,range of the leakage operating time is 0~799ms. It is a product with high accuracy, small size, light weight, exquisite appearance, easy to carry, is an ideal tool for a variety of leakage protector in site or in laboratory testing.


Main characteristics:

  • Handheld type, small and esay to operate


  • Can measure single phase or three phase all kinds of leakage protector


  • Auto test leakage operating current


  • Directly test leakage operating time


  • LCD display, intuitive reading

Technical indicators:


1. Rated voltage: AC220V,380V

2. Limited test voltage: below AC250V

3. Leakage current range: 15,30,50,75,100,150,200,250,300,500mA

4. Leakage operating time range: 0-799ms

5. Leakage current accuracy: 1 class

6. Operating time display accuracy: 0.5%(±2d)

7. Working environment temperature: 0℃-40℃

8. Working environment relative humidity: <85%

9. Outside dimension: 195*101*42mm



For more information , click this link to send us inquiry now !




Product pictures:
LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester 0
LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester 1
LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester 2
LBQ-II Handheld AC220V AC380V 500mA Leakage Current Tester 3
